PLUSCO 130
Lead & Zinc Free Copper Dope



Description


  • PLUSCO 130 Lead & Zinc Free Copper Dope is a premium extreme pressure anti-seize thread compound. Copper Dope provides a leak-proof connection and allows continuous sealing under adverse and varying pressure and temperature conditions. Copper Dope controls friction during make-up by allowing proper thread engagement thus insuring optimum resistance to leakage.
  • Copper Dope contains a balanced package of corrosion, rust and oxidation inhibitors blended in premium lithium base grease. PLUSCO 130 Lead & Zinc Free Copper Dope does not contain lead or any other hazardous materials. PLUSCO 130 Lead & Zinc Free Copper Dope allows ease of make-up and breakout under the most demanding conditions. Made up connections are not affected by high torque, vibration or load conditions.

Application


  • PLUSCO 130 Lead & Zinc Free Copper Dope is formulated to meet the rigid requirements of the entire drill string. It is also recommended as a casing and tubing high- pressure lubricant and sealant. PLUSCO 130 Lead & Zinc Free Copper Dope is also recommended for areas where high temperature conditions exist such as reactors, steam-lines, boilers, heat exchangers or cat-cracking units. Copper Dope is often used on connections when assembling down-hole pumps.

Package


  • 1 GAL PAIL
  • 2 GAL PAIL
  • 3.5 GAL PAIL
  • 5 GAL PAIL

Specifications


Color Copper Brown
Base Thickener Lithium
Specific Gravity 0.95-1.03
Oil Separation Nil (0.003%)
Worked Penetration @ 77 °F 310-340
NLGI Grade 1.5
Temperature 180 °F
Max. Make-Up Torque 311
Max. Break-Out Torque 187
Friction Factor 1
Service Rating -20 °F to +600 °F
Density 7.94-8.6
Dropping Point 405 °F
Water Resistant Yes
Oxidation Stability Very Good
Rust/Corrosion Inhibited Yes
Classification Sealant / Anti Galling Compound
